Buy P/N: 373154, Type: BFD-P HD 115.280 DN 1 from Boll Kirch in Turkey

BRAND	Boll Kirch
Product	P/N: 373154, Type: BFD-P HD 115.280 DN 1
Description	çift filtre
Internal code	4434048
Weight	70
Custom code	842139
Technical specification	Filter type: BFD-P HD M Case Size (G.Q) :115,280 size: 02 Nominal connection diameter: DN 1" connecting flanges according to: ASME, 300 lbs, RF Dimension sheet: similar to Z138270 fluid to be filtered: ammonia Fluid group according to PED: 1 Fluid type according to PED: gas Max. flow rate: 100.00 Nm³/h Maximum allowable pressure: 40.00 bar (g) perm. Operating temperature min: 0,00 °C perm. Max. operating temperature: 100,00 °C Pressure drop with clean sieves: < 0.1 bar at 100.00 Nm³/h Design and design: ASME VIII Div.1/ped2014/68/EU (without stamp) : Art. 4, para 3 Volume of container 2x: 0.50 litres Pre-check the drawing by: customer Pressure test according to: Boll & Kirch with certificate Material certificates: EN 10204/3.1 — Construction/acceptance — Preliminary inspection documents consisting of: calculation: yes drawings: yes BOM: yes 3-D model step format: yes Earthquake exposure: no Nozzle loads: no wind loads: no — Construction/application — PMI: no NACE: no — Construction/form certificates — Q-plan: FB-8-65 Q-Plan BFD-X gas FB-7-80 pressure test 3.1: min. 1.5 x design FB-7-80 pressure test 3.1: holding time 30 min. FB-7-88 gas pressure test 3.1: min. 1.1 x design Filter housing manufactured from: 316 L/316 Type of changeover valve: ball valve switching Material of diverter valve: 316 L/316 Switching valve internal parts: 316 L Cover seals made of: EPDM Circuit seals off: EPDM Item type: HC1-G VA Material of the element: stainless steel Number of disposable cartridges 2x: 1 Filter fineness: 5 μm Attached differential pressure indicator: without — Accessories/connectors — Vent: with plug 1/2" NPT emptying: with plug 1/2" NPT Differential pressure port: with 1/2" NPT plug — Accessories/nozzle orientation — Admission: 180° Exit: 180° Switch lever: 180° Earthing connection: 0° venting: 0° emptying: 0° wall mount: 0° differential pressure connection: 0° Manufacturer plate: 90°/270° — Accessories/differential pressure measurement — Pressure compensation line with 3 mm aperture: yes — Accessories/others — Grounding tab: yes Wall mount: yes Foot attachment: no Outer primer: WITHOUT Corrosion protection inside: WITHOUT

Discover the superior quality and performance of the Boll Kirch P/N: 373154, Type: BFD-P HD 115.280 DN 1 with Meltaş İç ve Dış Tic. Ltd. Şti. in Turkey . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The P/N: 373154, Type: BFD-P HD 115.280 DN 1 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of P/N: 373154, Type: BFD-P HD 115.280 DN 1 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Meltaş İç ve Dış Tic. Ltd. Şti. , we offer the P/N: 373154, Type: BFD-P HD 115.280 DN 1 at competitive prices and with the fastest delivery times across Turkey . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Meltaş İç ve Dış Tic. Ltd. Şti. ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the P/N: 373154, Type: BFD-P HD 115.280 DN 1 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Boll Kirch products, Meltaş İç ve Dış Tic. Ltd. Şti. is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
